Considering the Behavior of Doped SrTiO3 Ceramics

By Samudrapom DamMay 27 2022

This article discusses the changes in the behavior of strontium titanate (SrTiO₃) ceramics, specifically in their thermoelectric properties and crystal structure, after being doped with different elements such as niobium (Nb), tantalum (Ta), and lanthanum (La) in the context of thermoelectric power generation.

Image Credit: Isacco/Shutterstock.com

Limitations of Thermoelectric Material

Thermoelectric materials have gained considerable attention for harvesting energy from the waste heat liberated from electronic devices, industries, automobiles, and power plants.

The thermoelectric material efficiency is measured by the dimensionless thermoelectric figure of merit ZT = S² σTқ^-1, where σ refers to electrical conductivity/ S cm^-1, S is the Seebeck coefficient/ µVK^-1, қ is the thermal conductivity/ Wm^-1K^-1, T is the absolute temperature/K, and Z is the figure of merit.

However, achieving a high ZT is challenging owing to the interdependence of σ, қ, and S. To attain a high ZT, the thermoelectric material must possess a high power factor/S²σ value and a low thermal conductivity.

Typically, the Seebeck coefficient or electrical conductivity is enhanced by nano/micro structuring or doping approaches to increase the power factor of the thermoelectric material.

Significance of Perovskite-type SrTiO₃

A range of compounds of potential thermoelectric properties in a large temperature range can be synthesized by doping perovskite-type cubic SrTiO₃. The SrTiO₃-based oxide thermoelectric materials have gained prominence owing to their low cost, non-toxicity, and excellent redox flexibility and thermal stability.

Undoped SrTiO₃ acts as an insulator, which can be converted into a semiconductor by doping pentavalent elements in the B-site and trivalent elements in the A-site. The donor dopant with a higher cationic charge, such as Ta⁵⁺ and Nb⁵⁺, replaces the host cation titanium (Ti⁴⁺) with a lower charge in the doping process, which brings either more electrons or ions into the system compared to the host oxide and improves the electrical properties of SrTiO₃ ceramics.

Change in the Behavior of Doped SrTiO₃ Ceramics

A paper recently published in the journal Materials Today: Proceedings demonstrated changes in the thermoelectric properties and the structure of SrTiO₃ ceramics after the ceramics were doped with Nb/Ta or co-doped with Nb and Ta.

The lattice constant was increased in the Ta/Nb-doped SrTiO₃ compared to undoped SrTiO₃ due to the higher ionic radii of Ta and Nb dopants compared to the replaced host Ti atom.

However, the lattice constant remained the same in the Nb-Ta co-doped and Nb/Ta doped SrTiO₃ owing to the similar ionic radii of both Nb and Ta. The tolerance factor and unit cell volume of Nb/Ta substituted and co-doped SrTiO₃ also displayed no difference due to the same ionic radii of dopants.

The thermoelectric properties, such as the Seebeck coefficient and electrical conductivity, were evaluated in an inert atmosphere to prevent the reoxidation of the doped SrTiO₃ samples at extremely high temperatures.

In all doped samples, the electrical conductivity decreased with an increasing temperature, indicating the general metallic behavior of the Nb/Ta substituted and co-doped SrTiO₃ ceramics.

However, the Nb-doped SrTiO₃ samples displayed a typical semiconductor behavior as the electrical conductivity increased in Nb-doped SrTiO₃ samples till 570 K. In the Ta-doped SrTiO₃ samples, the electrical conductivity decreased consistently with the increasing temperature, which improved the metallicity of the samples.

Ta-Nb co-doped samples with an equal concentration of both dopants displayed the highest electrical conductivity of 235 S cm^-1 at 470 K due to the creation of more charged carriers compared to other doped samples.

Unlike the electrical conductivity, the Seebeck coefficient was increased in correspondence with the increasing temperature. The inverse relationship between the Seebeck coefficient and electrical conductivity resulted in a higher electrical conductivity when the Seebeck coefficient value was low. The Ta doping decreased the Seebeck coefficient value, while Nb doping increased the value in the samples.

In Ta doped samples, the Seebeck coefficient decreased considerably while the electrical conductivity was enhanced, indicating that the increase in the number of charge carriers in Ta doping was due to the increased oxygen vacancies. The highest Seebeck coefficient value of 190 µVK^-1 was observed at 1080 K for Nb-doped SrTiO₃ samples.

The power factor values increased with the rising temperature in all samples. Although the Ta and Nb co-doped samples demonstrated the highest electrical conductivity, their power factor values decreased with the rising concentration of Ta, owing to the substantial decrease in the Seebeck coefficient. The maximum power factor value of 250 µWm^-1K^-2 was observed at 900 K in the Nb-doped SrTiO₃ samples.

In another study published in the journal Chemistry of Materials, researchers investigated the thermoelectric properties and structure of lanthanum (La)-doped A-site-deficient SrTiO₃ (Sr_1−3x/2La_xTiO₃) ceramics sintered in nitrogen/5%hydrogen and air.

The optimized ZT values of 0.41 obtained for n-type Sr_{1 −3x/2}La_xTiO_3‑δ ceramics at 973 K with 0.125 ≤ x ≤ 0.175 was the highest reported thermoelectric ZT values for any perovskite-based SrTiO₃ ceramics.

The high ZT values were achieved by the close control of ceramic processing conditions and careful selection of starting compositions, which created defective perovskite lattices consisting of O- and A-site vacancies with mixed valent Ti⁴⁺ and Ti³⁺ on the B-site.

Although the optimized materials featured highly defective nonstoichiometric perovskites, they were resistant to rapid reoxidation in the air at temperatures up to 1273 K, which showed their potential in thermoelectric application such as n-type legs in thermoelectric generators.

To summarize, the doping approach has been found suitable for effectively improving the thermoelectric properties of perovskite-type cubic SrTiO₃. Thus, the approach can be potentially implemented for the synthesis of efficient thermoelectric materials with a high figure of merit.

More from AZoM: Use and Applications of Flame Atomic Absorption Spectroscopy

References and Further Reading

Charan Prasanth S., Jose, R., Vijay, A., Vineetha P., Venkata Saravanan K. Tuning thermoelectric properties of Nb and Ta co-doped SrTiO₃ ceramics. Materials Today: Proceedings. ISSN 2214-7853. 2022. https://doi.org/10.1016/j.matpr.2022.04.908

Lu, Z., Zhang, H., Lei, W., Sinclair, D.C., and Reaney, I. M. High-Figure-of-Merit Thermoelectric La-Doped A-Site-Deficient SrTiO₃ Ceramics. Chemistry of Materials. 28, 3, 925–935. 2016. https://doi.org/10.1021/acs.chemmater.5b0461
