Scientists from the University of Bath in the UK invent a screen that deforms beneath a user’s fingers, with the surface becoming softer or stiffer in direct response to force applied.
With digital maps, users will be able to toggle between street view, satellite view, topographical view etc. by changing finger pressure. Image Credit: Matt Sutton, University of Bath
A touch screen for digital devices that can be deformed through finger pressure, becoming softer or stiffer in direct response to force applied by the user, has been developed by computer scientists at the University of Bath.
DeformIO – as it has been named – is still a prototype and will require at least a decade of further development before it can be passed on to tech companies to be shaped into a commercial product, however its inventors regard it as groundbreaking technology.
They believe DeformIO has the potential to radically change the way people interact with the world in fields as diverse as commerce, communications, medicine and gaming.
Before making an online purchase, for instance, the shopper of tomorrow may be invited to ‘touch’ the fabric of a new sofa or ‘feel’ the softness of a pillow simply by pressing on their DeformIO phone display.
The deformable screen also has the potential to change the way users interact with files and apps on their devices. To delete a file, for instance, a person may find themselves pushing on the file icon until it stiffens and eventually ‘pops’ like a bubble.
“You’d be directly manipulating a digital object the way you normally would a physical one,” explained James Nash, a computer-science postgraduate at Bath and first author of a study describing the new technology, published this month.
Pinning Down the Display
Though this is not the first iteration of a deformable display, earlier models (made from movable touchscreen panels or rigid pins) have created a less continuous experience than DeformIO, relying on arrays of raised ‘pins’ lying beneath the display which, when depressed, lowered a section of screen. Such technology results in sharp breaks or steps between areas of the screen when pressure is applied.
DeformIO, which is made of silicone, works in an entirely new way, using pneumatics and resistive sensing (a technique that transforms physical forces into electric signals) to detect pressure.
With this technology, a user can depress the screen then run their finger across the surface to create a natural, continuous movement.
“Our screen allows users to perceive rich tactile feedback on a soft surface,” said Mr Nash.
“It gives the same benefits as today’s glass-based screens – which allow you to control your device by moving your finger fluidly across the surface – but with the added benefit of a person being able to use force to interact with their device at a deeper level.”
Another feature of the DeformIO is that it allows a user to apply forces to multiple areas on a screen simultaneously, with the display being able to distinguish between levels of pressure applied, creating degrees of softness appropriate to the force detected.
University of Bath computer scientist Professor Jason Alexander, who has been working on deformable screens for the past 10 years and is leading the research on DeformIO, says the 25 cm x 25 cm prototype developed in his lab has been built, “to explore a vision of devices with screens that you can push through and they can push back.”
He said: “We hope that in 10 to 20 years’ time, the concepts it embodies could be in your mobile phone. For now, we’re exploring the applications it might be best suited to.”
Possible Applications for DeformIO Include:
- Video games. During a battle sequence, for example, the display might deform as a player pushes an action button on the screen while also creating physical resistance through the screen when an opponent strikes back.
- Computer simulations for medical training. For example, a medical student might detect a cyst that’s invisible to the naked eye by palpating a screen.
- Car touchscreens to replace hard touchscreens. Stiffness cues from the deformable screen could help drivers find buttons or slides and receive ‘physical’ information back without taking their eyes off the road.
- Remote ‘physical contact’. Two people on a video call might be able to make ‘physical contact’ through their screens, where one person exerts finger pressure on their display and the person on the receiving end both sees and feels a depression on their own screen.
- Digital maps. A user would be able to toggle between street view, satellite view, topographical view and more, simply by changing the pressure exerted by a finger.
Expanding on the way DeformIO might work for digital maps, Mr Nash said: “You’d get an enormous amount of information from your map. For instance, by pushing into a city, you’d get instant demographical data, and by pressing on a specific shop, you’d know from its level of stiffness if it was open.”
The DeformIO display was introduced to the world this month at CHI 2024 – the ‘CHI Conference on Human Factors in Computing Systems’ – the leading international conference on Human-Computer Interaction.
The digital touchscreens of the future could let you 'feel' items through your phone
The digital touchscreens of the future could let you 'feel' items through your phone. Video Credit: University of Bath
