By Stefano Tommasone Ph.D.Reviewed by Lexie CornerDec 19 2024Electroplating is a technique that uses an electrical current to deposit a thin layer of metal onto a surface. It is widely used across industries to enhance material properties, such as durability, corrosion resistance, and aesthetic appeal.
Image Credit: BackWood/Shutterstock.com
Since its adoption in the mid-19th century, electroplating has become integral to product development and manufacturing. The process involves electrolytic deposition, where a direct current facilitates the coating of materials with metals such as gold, silver, copper, nickel, tin, or zinc, including both precious and non-precious metals.
The Electroplating Process Explained
The main components of an electroplating setup include the cathode (the object to be plated), the anode (a metal supplying ions for plating), and the electrolyte solution containing dissolved ions. In some cases, a reference electrode may be used to measure the potential more precisely, though this is primarily used in research and development settings.[1]
Metal coatings are deposited through electrochemical reactions occurring at the interface between the electrode and the electrolyte. The cathode and the anode are immersed in the electrolyte solution. When an electrical current passes through the cell, metal ions from the anode dissolve into the solution and migrate to the cathode, forming a coating on its surface.
The relationship between the amount of metal deposited and the electrical charge passed through the system is governed by Faraday’s law (Q = zmF, where z is the number of electrons, m is the number of moles, and F is Faraday's constant). Factors such as plating time, temperature, and solution composition can affect the quality and thickness of the deposited layer.
The process also includes preparation steps. The substrate is cleaned to remove contaminants, and an undercoat may be applied to enhance adhesion. Once plated, the surface is polished and finished. Commonly deposited metals include zinc, nickel, copper, and chromium, as well as precious metals like gold and silver.
How Does Electroplating Work | Reactions | Chemistry | FuseSchool
Electroplating in Industry: Advantages and Challenges
Electroplating provides several benefits in manufacturing, making it widely used across industries for both functional and decorative purposes. The process allows precise control over layer thickness, morphology, composition, and uniformity.
- In the automotive industry, electroplating is commonly used to improve the durability and appearance of components such as bumpers and wheel rims. Chrome plating, for example, enhances aesthetics with a reflective finish while also protecting surfaces from corrosion.
- In electronics, electroplating is applied to create conductive pathways and protect connectors and circuit boards. Metals like gold, silver, and nickel are often used to ensure low-resistance connections, improving both the performance and longevity of devices.
- In the fashion and jewelry industry, electroplating is commonly used to coat base metals with precious metals like gold, silver, or platinum. This creates visually appealing yet affordable products.[2]
- In aerospace and defense, robust coatings are often required to withstand extreme conditions. Electroplating provides corrosion resistance, thermal stability, and wear protection for critical components like turbine blades. It is also crucial for marine equipment, such as ship hulls, which are constantly exposed to seawater and biological agents.
Despite its advantages, electroplating presents challenges that require careful consideration. One significant concern is the use of chemicals such as cyanides and heavy metals, which pose environmental and health risks. Managing these substances adds complexity, as strict regulations govern waste disposal and emissions.
Additionally, the process can be energy-intensive, with significant energy requirements for maintaining the electrolytic cell and the lengthy duration of the plating process contributing to high operational costs and carbon emissions.
Another consideration is the release of metals from plated objects. Toxicological studies have reported concerns about prolonged contact with metals such as nickel, cadmium, and lead, prompting regulations to limit exposure to alloys containing these substances.
Ensuring consistent coating quality can be an additional challenge. Variations in temperature, current density, or electrolyte composition can cause defects such as pitting (small holes on the surface) or uneven deposition. Material limitations can also occur, as some substrates do not bond well with certain plating metals, often requiring pre-treatment steps.
Titrating Acid Mixtures in the Electroplating, Metals, and Electronics Industry
The Future of Electroplating
Recent years have seen a growing emphasis on developing more sustainable electroplating processes. Green electroplating explores non-toxic alternatives, such as ionic liquids and water-based electrolytes, to replace traditional chemicals like cyanides and heavy metals.
New methods for the management and control of wastewater, or the synthesis of new alloys, aim to minimize waste and reduce the environmental impact of the process. Advances in these areas not only improve safety for workers but also simplify compliance with environmental regulations.[3]
Emerging technologies, such as pulse electroplating (where the current is applied in short pulses) and microplating, offer greater control over coating properties.[4] These methods enable the deposition of ultra-thin, uniform coatings with tailored characteristics, creating opportunities for applications in nanotechnology and medical devices.
Electroplating is also being integrated into 3D printing to enhance the functionality of printed components. Controlled metal deposition on 3D-printed parts improves mechanical properties, refines surface characteristics, and supports the creation of complex shapes with high precision.[5]
Automation and AI-driven systems are increasingly contributing to the electroplating process. By optimizing parameters, reducing waste, and ensuring consistent quality, these technologies are making electroplating more efficient and reliable, opening new opportunities for electroplating in the future.
References and Further Reading
- Gugua, EC., Ujah, CO., Asadu, CO., Von Kallon, DV., Ekwueme, BN. (2024). Electroplating in the modern era, improvements and challenges: A review. Hybrid Advances. https://doi.org/10.1016/j.hybadv.2024.100286. Available: https://www.sciencedirect.com/science/article/pii/S2773207X24001477
- Giurlani, W., Zangari, G., Gambinossi, F., Passaponti, M., Salvietti, E., Di Benedetto, F., Caporali, S. Innocenti, M. (2018). Electroplating for Decorative Applications: Recent Trends in Research and Development. Coatings. https://www.mdpi.com/2079-6412/8/8/260
- Comparini, A., Del Pace, I., Giurlani, W., Emanuele, R., Verrucchi, M., Bonechi, M., Innocenti, M. (2023). Electroplating on Al6082 Aluminium: A New Green and Sustainable Approach. Coatings. https://www.mdpi.com/2079-6412/13/1/13
- Zehtab, M. Najafisayar, P. (2024). Influence of pulse-electroplating parameters on the morphology, structure, chemical composition and corrosion behavior of Co–W alloy coatings. Results in Surfaces and Interfaces. https://doi.org/10.1016/j.rsurfi.2024.100215, https://www.sciencedirect.com/science/article/pii/S2666845924000357
- Lazarus, N., Bedair, SS., Hawasli, SH., Kim, MJ., Wiley, BJ. Smith, L. (2019). Selective Electroplating for 3D-Printed Electronics. Advanced Materials Technologies. https://doi.org/10.1002/admt.201900126, https://onlinelibrary.wiley.com/doi/abs/10.1002/admt.201900126
