Woolpit, United Kingdom, 10th May 2016: Deben, a leading provider of in-situ testing stages together with innovative accessories and components for electron microscopy, reports on the application of their CT-Cool stage at the Steinbeis Center for Non-destructive Testing and Measurement, located at the DHBW Heidenheim, Germany.
It is being used to study the behaviour of various plastic materials under different temperature conditions. Professor Nico Blessing is Engineering Programme Director at the Baden-Württemberg Cooperative State University (DHBW) at Heidenheim. Located in the Steinbeis Center for Non-destructive Testing and Measurement, the research goals of the group include the analysis of the behavior of plastic materials. In particular, glass- and carbon-fiber reinforced parts are studied under variable temperature conditions. The aim of the research is to simulate environmental conditions of real life parts.
In situ testing of modern materials and measurement of complex parts under real environmental conditions like temperature, compression or tension is getting more and more relevant for the development of many products. This is particularly relevant in the automotive and aerospace industries. Several pan-European and national projects have been conducted in the last five years. Small and medium sized companies are interested in the results of this research because innovative materials such as composites are no longer just applied in these industries but also in areas such as leisure and sports.
Over the last three years, my students have worked to develop two different stages. The first offered tension and compression measurements with variable force control up to 5 kN. The second provided environmental control with adjustable temperature and humidity. We then selected the Deben stages because these gave us high accuracy in terms of load and temperature. Also, the stage is perfectly adapted for use in our CT system, a Zeiss METROTOM 800.
Professor Nico Blessing is Engineering Programme Director at the Baden-Württemberg Cooperative State University (DHBW) at Heidenheim
The work of the group is illustrated by this montage of four 3D images which show changes in density and pore size of an organic specimen at temperatures from -14.5 °C up to 160 °C.
The Deben Peltier stage for µXCT tomography systems allows samples to be imaged in freezing conditions. A dual layer polystyrene (optional carbon) window prevents icing and allows samples to be rapidly cooled to ‐20 °C. A variable height specimen holder allows samples to be placed at the optimum height for X‐Ray imaging and mounting adaptors are available for a range of µXCT stages. The cooling system is self-contained and does not require an additional water chiller. The connecting pipework is flexible and easily allows 360° rotation. To obtain full details of the Deben applications and product portfolio, please visit www.deben.co.uk.
