Dynamic and time-lapse CT with X-rays has rapidly emerged as an essential technique to understand material evolution, facilitating in situ investigations ranging from mechanical deformation to fluid flow in porous materials and beyond. Imaging of dynamic processes is one of the key applications at synchrotron facilities, pushing the time resolution more and more down with quite some success.
In the laboratory, image quality and spatial resolution have been significantly improved, often at the cost of temporal resolution, however. Recent developments at TESCAN XRE have made it possible to visualize and inspect the dynamic processes in the laboratory with a temporal resolution below 10 seconds. In this study, we explore the challenges and innovations that have led to this capability. Two different scan approaches: time-lapse CT and dynamic CT will be explained during an examination of germinating seeds.
Introduction
As a non-destructive technique, micro-CT is an optimal technique to take repetitive scans of the same sample over time. The combination of taking different scans over time is called dynamic or time-lapse CT. By doing so, the scans can demonstrate how materials form, deform, and perform over time or under certain external conditions. On the one hand, during the time interval, external parameters can be manipulated by using in-situ stages such as pressure or temperature stages. On the other hand, the sample itself can form or deform on its own (swelling, drying, growing, etc.).
Dynamic imaging of germinating seeds
The popularity of dynamic CT is drastically increasing, but still, not many people are performing dynamic experiments on a regular base. This can be explained by the fact that performing dynamic experiments has some practical challenges during every step of the process (acquisition, reconstruction, visualization, and analysis). Dedicated 4D designed workflows are needed to handle the complete workflow from acquisition to the analysis.
In this study, different approaches for both dynamic and time-lapse CT will be discussed. Dedicated hardware and software tools are being developed at TESCAN XRE to facilitate the execution of dynamic CT experiments in an intuitive and streamlined workflow.
Want to know more? Click here to read the full article.
