How to Use Saved EBSD Patterns in Specific Applications

From Dec 14 2017

Summary

EBSD mapping has become a standard microanalysis technique in modern electron microscopy.  Traditionally, an EBSD pattern has been collected and indexed to determine crystallographic and phase information in real time.  During this collection process, it is possible to save the collected EBSD patterns.

https://www.azom.com/images/webinars/ThumbImage_106.png

In this webinar, we will discuss possible applications using these saved EBSD patterns, including phase differentiation using ChI-Scan™, microstructural imaging using PRIAS™, improved indexing performance using NPAR™, advanced pattern indexing, and HR-EBSD.  The goal of this webinar is to show the additional information that can be determined using saved EBSD patterns to improve your materials characterization.
